Kinds of Jib Cranes
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast that measures up to 20 feet long. Jib cranes could move loads between any areas within the boom's arc of rotation. Light duty models are utilized inside factories and warehouses for loads weighing as much as 5 tons. The BestJibCranes.com web site features the major types of jib cranes as being either mast mounted, free-standing or wall-mounted.
Free Standing
Free-standing jib cranes are able to stand alone not requiring support from the building structure. The horizontal boom in this case is connected to a pivoting vertical column which is firmly anchored to the floor of the building. This kind of jib crane is able to rotate a full 360 degrees and requires a foundation made of either concrete or steel.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the bottom and the top. These pivots are connected to the building floor and the overhead steel structure. These jib-cranes offer 360 degrees of rotation with the advantage of not needing the massive foundation needed for free-standing units.
Wall Mounted
Wall mounted jib cranes are connected to the wall of the building instead of supporting a typical vertical column. These cranes offer a horizontal boom. These machine offer up to 200 degrees of rotation and are ideal in areas where the full 360 degree rotation is not required.
There are two model varieties, depending on how the boom is supported. One of the types utilizes a tie rod that is connected from above the wall to the boom. The other variety supports the boom from below by utilizing a cantilever brace which is also connected to the wall.
